Eaton 15KVA UPS 9SX 230V Toren / Rackmount Convertible 3U Online UPS 9SX15KPMCH

Productoverzicht

Eaton 9SX 15KVA 230V Toren/Rackmount Convertible 3U Online UPS 9SX15KPMCH De nieuwe Eaton 9SX 15K/20K UPS levert stabiele stroom voor kritieke IT-infrastructuur, industriële, productie- en medische apparaten.Met geavanceerde technologie om de efficiëntie van de dubbele omzetting te verbeteren en de ...

Belangrijkste kenmerken
Merknaam: Eaton
Modelnummer: Eaton 9SX UPS
Plaats van oorsprong: China
Certificering: CE
Leveringsvermogen: 1000 stuks/maand
Levertijd: 60 dagen
Betalingsvoorwaarden: T/T, Western Union, MoneyGram
Standaard Verpakking: Deeltjes
Product aangepaste attributen
Markeren

Eaton 15KVA UPS

,

UPS Eaton 15KVA

,

9SX15KPMCH

Naam van het product:
Eaton 9SX (AP)
Vermogensniveau:
15K-20KVA
Vormfactor:
Rack/toren
Technologie:
Online UPS
Nominale frequentie:
40 Hz 70 Hz
Inlaatspanning:
1 fase 220/230/240V; 3 fase 380/400/415V
De waaier van het inputvoltage:
160 V~300 V volle belasting; 100~160 V liner derating
Geschatte inputfrequentie:
50 Hz/60 Hz
Systeemverenigbaarheid:
TN-S / IT
Invoer-uitvoerfaseverbinding:
Input-output 3-1, 3-3, 1-1
Nominale uitgangsspanning:
1 fase 220/230/240V; 3 fase 380/400/415V
THDV:
1% lineaire belasting; 3% niet-lineaire belasting
Outputverbinding:
Eindblok
Interne batterijen:
Geen. Minimaal 2x EBM's om backup tijd te bieden.
Batterijspanning:
±240V (instelbaar tot ± 192V, gebruik met de juiste batterij)
Laadstroom:
0~13A instellen
Verrichtingstemperatuur:
0 °C ~ 50 °C (0 ~ 40 °C zonder afkoeling 40 ~ 50 °C afkoeling tot 50%)
Geluidsniveau:
55 dB
Veiligheid:
CE/TLC/RCM
Energiebesparing:
CQC
Productbeschrijving

Eaton 9SX 15KVA 230V Toren/Rackmount Convertible 3U Online UPS 9SX15KPMCH



De nieuwe Eaton 9SX 15K/20K UPS levert stabiele stroom voor kritieke IT-infrastructuur, industriële, productie- en medische apparaten.Met geavanceerde technologie om de efficiëntie van de dubbele omzetting te verbeteren en de voetafdruk te verminderenEaton's 9SX product met zijn robuustheid in ontwerp voor hash-omgevingen of toepassingen buiten een communicatieruimte.







Productspecificaties

Merknaam:Eaton
Vormfactor:Rack/toren
Nummer van het onderdeel:9SX15KPMAU
Website van de fabrikant
Productmodel:9SX15K
Productnaam:9SX15K 15kVA UPS-rack/toren
Productserie:9SX

Productsoort:Dual Conversion Online UPS
